PressureDisk – Temperature and Pressure Logger

PressureDisk – Temperature and Pressure Logger

Code: TS13PRD
Manufacturer: Tecnosoft – Italy
Origin: Italy

Product Information:

• Suitable for various applications, waterproof device

• Meets medical standards and ISO (data is non-editable in the software)

• Dimensions: Logger body: H43.22 x Ø35 mm, ½ G thread: 55 mm, Temperature probe: L20 x Ø3mm

• Materials: Stainless steel AISI 316L and PEEK plastic (food-grade)

Temperature Parameters:

• Range: -40°C to 140°C

• Resolution: 0.02°C

• Accuracy: ±0.1°C (within calibration range)

• Standard Calibration Points: 25/50/75/100/121/140°C

Pressure Parameters:

• Range: 0 bar to 5 bar (absolute pressure)

• Resolution: 2 mbar

• Accuracy: ±15 mbar (within calibration range)

• Standard Calibration Points: 0.05/1/2/3/4 bar

Additional Specifications:

• Memory Capacity: 27,264 values

• Recording Interval: From 1 second onwards

• Power Supply: Replaceable battery (records up to 6,000,000 values with 1-second interval at 25°C, battery life decreases depending on usage temperature)

• Protection Rating: IP68

• Compatible with: DickInterface HS, Universal Multibay

• Software: HumiPressureDisk (Free), TS Manager

• Included: Calibration certificate from the manufacturer
